Honey extractor

This machine, made entirely of acid-resistant stainless steel, is designed for the beekeeper seeking effective improvements and a faster workflow in the apiary, while maintaining honey quality at the highest level. With this professional honey extraction machine you can uncap the hive frames and extract the honey with a horizontal honey extractor.

The machine consists of the following components:
- Mechanical uncapping machine
The uncapping machine is equipped with knives heated by a closed-circuit hot-water system, ensuring optimal performance. The uncapping machine operates at a speed of 4-6 frames per minute.

- Press for the cappings from the uncapped frames
During uncapping, the cappings fall into the press. The press has a capacity of 100 kg/h and separates the honey from the wax.

- Conveyors
While the separated honey flows to a filter sieve, the pressed wax is carried to a dedicated bin. At the same time the already uncapped frames are transported via the conveyor to the honey extractor. Using a manual trolley, the frames are placed into the honey extractor.

- Honey extractor
The honey extractor holds 40 frames. The extractor lid is fitted with gas springs that make opening and closing very easy. After extraction, the honey flows automatically to a vertical sieve. The honey extractor is 137 cm long, 115 cm wide and 190 cm high.

- Collection table
After extracting the honey, the frames can be placed on the collection table.

- Collection tank
After filtering the honey through the vertical sieve, it flows into a collection tank with a capacity of 120 L.

The components of this machine run on 230V power. The overall dimensions of the machine are: length 500 cm, width 170 cm and height 190 cm. The total weight is 419 kg.
